For three phase asynchronous electric motors, the start-up process is a critical stage that significantly affects performance and service life. Two common methods of starting electric motors are voltage modulation and frequency modulation. These techniques help create a more balanced starting process, minimizing mechanical stress on the motor. However, when a motor is started at normal operating voltage, it may encounter a series of problems, including jitter, mechanical resonance, and inertia changes. This article explores the causes of motor jitter during start-up and power-down, and how modulation techniques can mitigate these effects.
Starting process of electric motor
Electric motors are designed to convert electrical energy into mechanical energy. However, the transition from stationary to operating speed can be challenging. When a motor is energized at normal operating voltage, it experiences a sudden surge in current. This sudden change can cause mechanical instability, which can lead to judder—an oscillation or vibration that can harm the performance of the motor.
Judder occurs due to rapid acceleration of the rotor, which can cause the rotor to move beyond its intended position. This overshoot is often exacerbated by the inertia of the rotor and the load it drives. The mechanical parts of the motor, including bearings and windings, may not react quickly enough to sudden changes in speed and torque, causing resonance. This mechanical resonance can amplify jitter and form a feedback loop, further damaging the stability of the motor.
Voltage and frequency modulation
To solve these problems, voltage and frequency modulation techniques are used. When you use voltage modulation to start a motor, the voltage gradually increases, allowing the motor to accelerate to its operating speed more smoothly. This gradual increase helps maintain a balanced start-up process, thereby reducing the possibility of chatter and mechanical resonance. The motor is put under less stress, resulting in longer life and improved reliability.
Frequency modulation, on the other hand, involves adjusting the power frequency to control the speed of the motor. By starting the motor at a lower frequency and gradually increasing the frequency, the motor can achieve more controllable acceleration. This approach not only minimizes jitter but also improves the overall efficiency of the motor.
Effects of power failure
A power outage can also cause the motor to vibrate when it is restarted. During a sudden power outage, the three phase induction motor may suddenly stop, causing the rotor to lose momentum. After power is restored, the motor may again be subject to a sudden inrush of current, causing problems similar to those experienced during normal startup. Changes in inertia combined with mechanical resonance can cause severe vibrations that can cause damage over time.
In short, the starting process of an electric motor is a complex interaction of electrical and mechanical forces. When electric motors are started at normal operating voltages, they may experience jitter, mechanical resonance, and inertia changes that affect performance. However, using voltage and frequency modulation techniques can create a more balanced startup process, reducing the likelihood of these problems. Understanding the causes of motor vibration during startup and power outages is critical to optimizing motor performance and ensuring service life. By implementing effective starting strategies, engineers and technicians can improve the reliability and efficiency of electric motors in a variety of applications.
